Pneumatic Flat Hot Stamper with Conveyer
Product Details:
| Place of Origin: |
China |
| Brand Name: |
easy |
| Certification: |
CE |
| Model Number: |
HST-1050C |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 PC |
| Packaging Details: |
woodencase |
| Delivery Time: |
3 days |
| Payment Terms: |
TT |
| Supply Ability: |
1000PCS/Month |
Contact Now
Detailed Product Description
Pneumatic Flat Hot Stamper with Conveyer
Price Term:FOB GuangZhou
Payment Terms:TT/LC
Packing:Wooden case
Lead Time:Within 10 days
Standards Certificate:CE
Usage:Cap gilding;Toy gilding, small object gilding;Small plastics part gidling
Technical Parameter:
1. Hot plate area:100×150 mm
2. Working table area:75 ×125mm
3. Max printing pressure:2,000－3000 Kg
4. Up and down distance:45mm
5. Heat wattage:1000W
6. Foil in feed: Motor Drive
7. Temperature adjustment:0-300oC .
8. Station Number: 8.
9. Stamping Head drive:Pneumatic-drive
10.Foil collecting method: Morot-drive , Collecting time adjustable
11.Temperature controlling: Heating tube heat up,Automatically temperature
controlling,temperature free setting
12.Press adjustment way :Up-down of working table
13.Working table :Micro-adjustment device
14.Usage: Small object gilding ,Woodware Baking,Plastics Bronzing
Production Advantage ︰
1. Microcomputer control run.
2 Heating thermostat temperature stability.
3 Vertical pressure cylinder design, strong pressure.
4 Stamping pressure, temperature, hot pressing time is adjustable.
5 Three-dimensional and angle can be adjusted.
6 Automatic document feeder, the collection of paper, and adjustable.
7 Can be implemented in accordance with requirements of the installation of photocell pitch
control.
8 Stamping head height can be flexibly adjusted.
9.Conveyer table, Saving preparation time gilt, greatly improved production efficiency.
